What is the alarm and trip schedule?

image1687×1125 228 KB

2

What is the alarm and trip schedule?

Alarm and trip schedule is an engineering record that shows the priority and configuration for DCS and SIS implementation for each monitored instrument, including its alarm set points and trip set points.

Purpose and key fields

  • Tag and loop number location and usual operating value.
  • Units of measurement and the range of measurements.
  • There are alarm levels for warning and escalation, as well as trip levels that might cause actions like shutting down, blocking, or isolating.
  • Priority latching or not latching deadband and delay.
  • Annunciation class HMI text operator action and owner.
  • Reference for calibration interval and test technique.

Practical plant guidance

  • Get set points from process design HAZOP and transient experiments.
  • To avoid annoyance trips, use graded responses with warnings that come one after the other.
  • For each trip, make sure it has a documented safety purpose and that the DCS and SIS schedules are in sync.
  • Add human characteristics to clear HMI text and short operator instructions.
  • Use engineering change control so that every change to a defined point is logged and revalidated.

Troubleshooting and maintenance

  • Check the audit schedule against the real DCS and SIS setup during turnarounds.
  • Follow the protocol for test trips and write down the outcomes.
  • Trend annoying alarms and use rationalization by changing the deadband delay or priority instead of turning off alarms.
  • Keep track of version control by linking it to instrument datasheets and signed approvals.
  • Check the schedule every year and after any changes to the facility, and make sure operations and maintenance are involved in the assessments.

This method makes sure that alarm and trip settings keep people safe while causing as little disturbance to operations as possible. Train operators on how to respond to alarms, including how to escalate them and how to do simulated drills to check how people respond and make alarm management more reliable.
